tubelectron
Super Member
Approaching the end : NFB C and R, Pilot Lite, and input shielded cable are still to be installed... Oh, and the fuse in his socket !
T
T

Verey nice. What did you use to punch or cut the cap can hole?




I have dreams of using a multi-way gang rotary switch to handle screen grids, bias voltage, and NFB resistors....
Use it and you owe me a decent meal.![]()


Can minimize or eliminate the change in resistor value if the screens connect to the same B+ point as the output transformer does. That should have all idle voltage the same in both modes, so same bias needed. 6.8K is an awful large screen resistor too, normally its not more than about 1K specifically to keep it from sagging and causing performance issues.
That will also get more power in pentode mode. I'd expect closer to 4 watts out of a 6v6 at reasonable voltage.


Building a logical layout like this makes fixing and modifying, even years later — so much easier.this is excellent work. im gobsmacked by how tidy and compact it is. im eager to rereD thru the entire
build thread in one sitting.
